Tractor · Unverified
CBT 1000
CBT 1000. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Weight
2740 kg
Hover a source tag to verify
Overview
ManufacturerCBTReference
Built in BrazilReference
Two-wheel driveReference
Mechanical disc brakesReference
Open operator station.Reference
Engine
Perkins 3.3L 4-cyl dieselReference
Fuel tank60.0 LReference
Perkins 4.203Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Air cleaneroil bathReference
Compression17.4:1Reference
Rated RPM2000Reference
Torque209.9 NmReference
Torque RPM1250Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Oil capacity8.0 LReference
Transmission
6-speed gearReference
TransmissionKruppReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutch11-inch Borg dry discReference
Oil capacity40.0 LReference
PTO & Hydraulics
Rear PTO Type543Reference
Dimensions
Wheelbase186 cmReference
Weight2740 kgReference
Front tire6.00x16Reference
Rear tire13.00x28Reference
Ag front6.00x16Reference
Ag rear13.00x28Reference
Ag front7.50x16Reference
Ag rear14x30Reference
Ag rear15x30Reference
Ag rear12x38Reference
Length309 cmReference
Height (hood)150 cmReference
Operating weight2740 kgReference
Ballasted weight3319 kgReference
Front tread151 to 210 cmReference
Rear tread147 to 204 cmReference
Electrical
Charging systemgeneratorReference
Charging volts12Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
