Tractor · 1954Unverified
Farmall Super A-1
Farmall Super A-1 — Row-Crop tractor. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Hover a source tag to verify
Overview
ManufacturerFarmall (a part of International Harvester)Reference
Row-Crop tractorReference
Total built1,672Reference
The Super A-1 used the C123 engine, instead of the C113 used in the Super A. There were no decals or other markings to indicate the larger engine, but the prefix on the serial number plate changed from FAA to FAA-1.Reference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Variants
Super A-1row-crop chassisReference
Super AV-1high-crop chassis (vegetable)Reference
Super AC113 engineReference
Engine
International Harvester 2.0L 4-cyl gasolineReference
Fuel tank41.6 LReference
International Harvester C-123Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke79 x 102 mmReference
Compression6:1Reference
Rated RPM1450Reference
Starter volts6Reference
Coolant capacity14.2 LReference
Oil capacity4.7 LReference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Clutch228.6mm dry discReference
Oil capacity4.7 LReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase180 cmReference
Front tire5.00-15Reference
Rear tire9-24Reference
Ag front5.00-15Reference
Ag rear9-24Reference
Length271 cmReference
Width141 cmReference
Height (steering wheel)163 cmReference
Height (exhaust)207 cmReference
Clearance (front axle)56 cmReference
Clearance (rear axle)54 cmReference
Front tread109 cmReference
Front tread111 to 162 cmReference
Rear tread101 to 172 cmReference
Super A-1 Serial Number Location
Right side of seat support.Reference
Super A-1 Serial Numbers
1954356001Reference
Final357958Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter21 cmReference
Width15 cmReference
Speed352.65 meters/minReference
Electrical
GroundpositiveReference
Charging systemgeneratorReference
Battery volts6Reference
Speeds
With 9-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
