Tractor · 1980Unverified
Iseki T5000
Iseki T5000 — Utility tractor · 43 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
43 hp
Weight
5214 to 5721 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS. Cab available with heater.Reference
Variants
2-45similar White modelReference
Engine
Isuzu 2.8L 4-cyl dieselReference
Fuel tank60.2 LReference
Engine35.3 kWReference
Isuzu 4BA1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
Bore/Stroke98 x 92 mmReference
Power35.3 kWReference
Air cleanerdry with pre-cleanerReference
Compression19:1Reference
Rated RPM2250Reference
Starter volts12Reference
Transmission
20-speed gearReference
TypegearReference
Gears20 forward and 4 reverseReference
Clutch275mm dry discReference
Five gears (1-5), plus reverse (R), in two ranges with additional creeper range.Reference
PTO & Hydraulics
PTO (claimed)32.1 kWReference
Typeopen centerReference
Steering flow30.3 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear PTOindependentReference
ClutchhydraulicReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1814Reference
Engine RPM869@2250Reference
Dimensions
2WD Wheelbase199 cmReference
4WD Wheelbase203 cmReference
Weight5214 to 5721 poundsReference
Front tire6.50-16Reference
2WD Rear tire14.9/13-28Reference
2WD Standard tires (ag)Front: 6.50-16. Rear: 14.9/13-28Reference
4WD Standard tires (ag)Front: 8.3-24. Rear: 14.9/13-28Reference
Length348 cmReference
Width183 cmReference
Height240 cmReference
2WD Weight2365 kgReference
4WD Weight2595 kgReference
2WD Ground clearance33 cmReference
4WD Ground clearance31 cmReference
2WD Front tread132 to 192 cmReference
4WD Front tread150 cmReference
Rear tread140 to 201 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps30Reference
Batteries2Reference
Battery volts12Reference
Battery AH80Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
