Tractor · 1980Unverified
Iseki TL4500
Iseki TL4500 — TL Series · 44 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
44 hp
Weight
3792 to 4343 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Four-post ROPS with canopy. Open station available.Reference
Engine
Isuzu 2.4L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine33.1 kWReference
Isuzu C240Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke86 x 102 mmReference
Power33.1 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speedReference
Gears18 forward and 6 reverseReference
PTO & Hydraulics
Rear TypeJIS1Reference
Controlposition and draft controlReference
Rear PTO Type540 (1.375)Reference
Engine RPM602@2600Reference
Engine RPM734@2600Reference
Engine RPM959@2600Reference
Engine RPM1566@2600Reference
Dimensions
Wheelbase198 cmReference
Weight3792 to 4343 poundsReference
Front tire6.00-18Reference
2WD Rear tire12.4-32Reference
2WD Standard tires (ag)Front: 6.00-18. Rear: 12.4-32Reference
4WD Standard tires (ag)Front: 8.3-20. Rear: 12.4-32Reference
Length341 cmReference
Width154 cmReference
Height (ROPS)221 cmReference
Height (exhaust)205 cmReference
Ground clearance41 cmReference
2WD Front tread115 to 154 cmReference
4WD Front tread121 to 152 cmReference
Rear tread121 to 162 cmReference
2WD Open1720 kgReference
2WD ROPS1814 kgReference
4WD Open1875 kgReference
4WD ROPS1969 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
