Tractor · 1979Unverified
Iseki TS2420
Iseki TS2420 — Compact Utility tractor · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
863 kg
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical standardReference
SteeringmanualReference
Mechanical shoe brakesReference
Open operator station.Reference
Variants
TS24202WDReference
TS2420F4WDReference
Engine
Isuzu 1.2L 2-cyl dieselReference
Fuel tank16.3 LReference
Engine17.9 kWReference
Isuzu 2AB1Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.2 LReference
Power17.9 kWReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Torque67.8 NmReference
Torque RPM2000Reference
StarterelectricReference
Starter volts12Reference
Transmission
18-speedReference
Gears18 forward and 6 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Pressure137.9 barReference
Pump flow11.7 lpmReference
Rear Type1Reference
ControlPosition controlReference
Rear PTOtransmissionReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase137 cmReference
Weight863 kgReference
Front tire6.00-14Reference
Rear tire8.3/8-24Reference
Standard tires (ag)Front: 6.00-14. Rear: 8.3/8-24Reference
Length267 cmReference
Width124 cmReference
Height195 cmReference
Ground clearance25 cmReference
Front tread94 cmReference
Rear tread96 to 121 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
