Tractor · 1976Unverified
Iseki TS3110
Iseki TS3110 — Compact Utility tractor · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
2513 to 2976 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Variants
TS3110F4WDReference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank29.9 LReference
Engine22.8 kWReference
IsekiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Power22.8 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speedReference
18-speed creeperReference
Gears9 forward and 3 reverseReference
TypecreeperReference
Gears18 forward and 6 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type540 (1.375)Reference
Engine RPM630@2500Reference
Engine RPM773@2500Reference
Engine RPM990@2500Reference
Engine RPM1547@2500Reference
Dimensions
2WD Wheelbase175 cmReference
4WD Wheelbase178 cmReference
Weight2513 to 2976 poundsReference
Front tire5.00-15Reference
2WD Rear tire12.4/11-24Reference
2WD Standard tires (ag)Front: 5.00-15. Rear: 12.4/11-24Reference
4WD Standard tires (ag)Front: 6.00-16. Rear: 12.4/11-24Reference
Length310 cmReference
Width147 cmReference
Height199 cmReference
2WD Weight1139 kgReference
4WD Weight1349 kgReference
2WD Ground clearance36 cmReference
4WD Ground clearance32 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
