Tractor · 1978Unverified
Iseki TX1300
Iseki TX1300 — Compact Utility tractor · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
1067 to 1124 pounds
Hover a source tag to verify
Overview
ManufacturerIsekiReference
Compact Utility tractorReference
Two- or four-wheel driveReference
Manual steeringReference
Drum brakesReference
Open operator station.Reference
Variants
TX1300F4WDReference
G152similar Bolens modelReference
G154similar Bolens modelReference
Engine
Mitsubishi 0.7L 2-cyl dieselReference
Fuel tank12.1 LReference
Engine (gross)11.2 kWReference
Mitsubishi KE70Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement0.7 LReference
Bore/Stroke73 x 80 mmReference
Power (gross)11.2 kWReference
Starter typeelectricReference
Oil capacity2.6 LReference
Exhaust valve clearance0.356 mmReference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Oil capacity12.3 LReference
PTO & Hydraulics
Pressure117.7 barReference
Total flow10.2 lpmReference
Rear TypeJIS-0Reference
Rear lift (at ends)380 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM472@2700Reference
Engine RPM752@2700Reference
Engine RPM1177@2700Reference
Dimensions
Wheelbase121 cmReference
Weight1067 to 1124 poundsReference
Front tire4.50-10Reference
2WD Rear tire8-16Reference
2WD Standard tires (ag)Front: 4.50-10. Rear: 8-16Reference
4WD Standard tires (ag)Front: 5.00x12. Rear: 8-16Reference
Length192 cmReference
Width98 cmReference
Height (steering wheel)119 cmReference
2WD Weight483 kgReference
4WD Weight509 kgReference
Ground clearance26 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Battery AH45Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
