Tractor · 1959Unverified
J.I. Case 614-B
J.I. Case 614-B — 600B Series. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Built in Rock Island, Illinois, USAReference
Total built125Reference
Two-wheel driveReference
Variants
610Bstandard frontReference
611Brow-crop frontReference
614BorchardReference
Engine
J.I. Case 2.7L 4-cyl gasolineReference
J.I. CaseReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke93 x 105 mmReference
Air cleaneroil bathReference
Compression7.3:1Reference
Rated RPM2250Reference
Starter typeelectricReference
Transmission
8-speedReference
TransmissionCase-o-MaticReference
Gears8 forward and 2 reverseReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
