Tractor · 1929Unverified
Lanz Bulldog HR6
Lanz Bulldog HR6 · 38 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
38 hp
Hover a source tag to verify
Overview
ManufacturerLanzReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Drive2WDReference
Engine
Lanz 10.3L 1-cyl oilReference
Engine28.3 kWReference
LanzReference
oilReference
1-cylinderReference
liquid-cooledReference
Displacement10.3 LReference
Bore/Stroke225 x 260 mmReference
Power28.3 kWReference
Rated RPM630Reference
Transmission
3-speedReference
TransmissiongearReference
Gears3 forward and 1 reverseReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
