Tractor · 1978Unverified
Acremaster 402
Acremaster 402 — 400 Series · 249 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
249 hp
Weight
9599 kg
Hover a source tag to verify
Overview
ManufacturerAcremasterReference
Four-wheel Drive (4WD) tractorReference
Built in Merredin, AustraliaReference
Four-wheel driveReference
Articulated power steeringReference
Cab standard with air-conditioning.Reference
Engine
Mercedes-Benz 12.8L 8-cyl dieselReference
Engine185.7 kWReference
Mercedes-Benz OM402Reference
dieselReference
8-cylinderReference
liquid-cooled V8Reference
Displacement12.8 LReference
Bore/Stroke125 x 130 mmReference
Power185.7 kWReference
Compression17.5:1Reference
Rated RPM2350Reference
Torque833.9 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
9-speed gearReference
TransmissionAcremasterReference
TypegearReference
Gears9 forward and 3 reverseReference
Dimensions
Weight9599 kgReference
Front tire23.1x30Reference
Rear tire23.1x30Reference
Ag front23.1x30Reference
Ag rear23.1x30Reference
Length580 cmReference
Width382 cmReference
Height (exhaust)329 cmReference
Speeds
With 23.1x30 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
