Tractor · 1918Unverified

Advance-Rumely OilPull G 20/40

Name: Advance-Rumely OilPull G 20/40
Brand: Advance-Rumely

Advance-Rumely OilPull G 20/40 — Standard-tread tractor · 20 hp. Reference specifications; pending source verification.

The Advance-Rumely OilPull G 20/40 is a tractor with an output of 20 hp, classified as a compact option in its range. It was produced between 1918 and 1924. The tractor features a 2-cylinder liquid-cooled engine driving through a two-wheel drive system with a 2-speed gearbox. Its listed weight is 5842 kg, suitable for tasks covering approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Max power

22.4 kW

Weight

5842 kg

Catalogue coverage

Variants represented

Richest spec table

45 rows

Recorded power

20 hp

Recorded weight

5842 kg

Transmissions

2-speed gear

Production years

1918-1924

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAdvance-RumelyReference

Standard-tread tractorReference

Built in La Porte, Indianam USAReference

Two-wheel driveReference

Canopy over open platform.Reference

Engine

Rumley 16.5L 2-cyl keroseneReference

Fuel tank155.2 LReference

Aux. fuel3.8 LReference

Drawbar (claimed)14.9 kWReference

Belt (claimed)29.8 kWReference

Drawbar (tested)22.4 kWReference

Belt (tested)34.4 kWReference

RumleyReference

keroseneReference

2-cylinderReference

liquid-cooled horizontal opposedReference

Displacement16.5 LReference

Bore/Stroke203 x 254 mmReference

Rated RPM450Reference

Coolant capacity66.2 LReference

Belt power (max)34.4 kWReference

Max power22.4 kWReference

Transmission

2-speed gearReference

TypegearReference

Gears2 forward and 1 reverseReference

Dimensions

Weight5842 kgReference

Front tire44x8Reference

Rear tire64x20Reference

Ag front44x8 steelReference

Ag rear64x20 steelReference

Length444 cmReference

Width226 cmReference

Height274 cmReference

OilPull G 20/40 Serial Numbers

191810425Reference

191910751Reference

1920G741Reference

1921G1728Reference

1922G2242Reference

1923G2690Reference

1924G3559Reference

FAQ: How to read a serial number table.Reference

Test results

Kerosene 2-speed 2WDMay 6 - 22, 1920Link: Nebraska Tractor Test 11 fileReference

Belt fuel use (max)21.6 l/hourReference

Drawbar performanceReference

Max pull2887 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
