Tractor · Unverified
Ag King AK2040
Ag King AK2040 — Jinma built · 20 hp. Reference specifications; pending source verification.
The Ag King AK2040 is a tractor rated at 20 hp — making it one of the more compact options in its class. Power comes from a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. Listed weight is 1120 kg, and it is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1120 kg
Catalogue coverage
Variants represented
2
Richest spec table
40 rows
Recorded power
20 hp
Recorded weight
1120 kg
Transmissions
12-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorAg KingReference
ManufacturerJinmaReference
Built in Yancheng City, ChinaReference
The Ag King 2040 is similar to the Jinma JM-224Reference
Four-wheel driveReference
Steeringhydrostatic powerReference
Engine
1.4L 3-cyl dieselReference
Engine14.9 kWReference
380Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Power14.9 kWReference
Rated RPM2400Reference
Oil capacity3.5 LReference
Coolant capacity9.8 LReference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Oil capacity12.3 LReference
Capacities
Fuel20.8 LReference
PTO & Hydraulics
Hydraulic system9.1 LReference
Capacity9.1 LReference
Steering flow32.6 lpmReference
Rear TypeIReference
Rear lift367 kgReference
Rear PTOtransmissionReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase165 cmReference
Weight1120 kgReference
Front tire6.00-12Reference
Rear tire8.3-24Reference
Ag front6.00-12Reference
Ag rear8.3-24Reference
Lawn/turf front26x7.5-12Reference
Lawn/turf rear11.2-20Reference
Length304 cmReference
Width137 cmReference
Height215 cmReference
Ground clearance29 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
