Ag King AK2840
Ag King AK2840 — Jinma built · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1315 kg
Hover a source tag to verify
Overview
DistributorAg KingReference
ManufacturerJinmaReference
Built in Yancheng City, ChinaReference
The Ag King 2840 is similar to the Jinma JM-254Reference
Four-wheel driveReference
Steeringhydrostatic powerReference
Engine
1.5L 3-cyl dieselReference
Engine17.9 kWReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Power17.9 kWReference
Rated RPM2350Reference
Oil capacity4.5 LReference
Coolant capacity9.8 LReference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
Oil capacity12.1 LReference
Capacities
Fuel22.0 LReference
PTO & Hydraulics
Hydraulic system9.1 LReference
Capacity9.1 LReference
Steering flow32.6 lpmReference
Rear TypeIReference
Rear lift396 kgReference
Rear PTOtransmissionReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase164 cmReference
Weight1315 kgReference
Front tire6.00-16Reference
Rear tire9.5-24Reference
Ag front6.00-16Reference
Ag rear9.5-24Reference
Length299 cmReference
Width144 cmReference
Height220 cmReference
Ground clearance30 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
