Tractor · Unverified
Ag King AK3540
Ag King AK3540 — Jinma built · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1766 kg
Hover a source tag to verify
Overview
DistributorAg KingReference
ManufacturerJinmaReference
Built in Yancheng City, ChinaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Engine
1.4L 4-cyl dieselReference
Engine26.1 kWReference
485Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Power26.1 kWReference
Rated RPM2400Reference
Oil capacity6.1 LReference
Coolant capacity7.6 LReference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
Oil capacity18.0 LReference
Capacities
Fuel30.3 LReference
PTO & Hydraulics
Hydraulic system8.3 LReference
Capacity8.3 LReference
Steering flow45.4 lpmReference
Rear TypeIReference
Rear lift498 kgReference
Rear PTOtransmissionReference
Rear PTO Type540/720Reference
Dimensions
Wheelbase167 cmReference
Weight1766 kgReference
Front tire7.5-16Reference
Rear tire11.2-24Reference
Ag front7.5-16Reference
Ag rear11.2-24Reference
Length307 cmReference
Width137 cmReference
Height215 cmReference
Ground clearance29 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
