Ag King AK4540
Ag King AK4540 — Jinma built · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
2109 kg
Hover a source tag to verify
Overview
DistributorAg KingReference
ManufacturerJinmaReference
Built in Yancheng City, ChinaReference
The Ag King 4540 is similar to the Jinma JM-454Reference
Four-wheel driveReference
Engine
3.0L 3-cyl dieselReference
Engine33.6 kWReference
310Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Power33.6 kWReference
Rated RPM2400Reference
Oil capacity5.9 LReference
Coolant capacity12.5 LReference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
Oil capacity30.3 LReference
Capacities
Fuel47.3 LReference
PTO & Hydraulics
Hydraulic system12.5 LReference
Capacity12.5 LReference
Rear TypeIReference
Rear lift680 kgReference
Rear PTOtransmissionReference
Rear PTO Type540/720Reference
Dimensions
Wheelbase194 cmReference
Weight2109 kgReference
Rear tire12.4-28Reference
Ag rear12.4-28Reference
Length342 cmReference
Width160 cmReference
Height266 cmReference
Ground clearance35 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
