Lawn Tractor · 1994Unverified
AGCO 1615H
AGCO 1615H — Model year 1994-19971997-2002 · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
244 kg
Hover a source tag to verify
Overview
DistributorAGCOReference
ManufacturerSimplicityReference
Lawn tractorReference
Built in Port Washington, Wisconsin, USAReference
Original price was $3,775 in 1996Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
15HP Kohler 426cc 1-cyl gasolineReference
Fuel tank15.1 LReference
Kohler CV15SReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement26 ciReference
Bore/Stroke90 x 67 mmReference
Power (gross)11.2 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionHydro-GearReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Mid PTO TypepulleyReference
Dimensions
Wheelbase121 cmReference
Weight244 kgReference
Front tire15x6.00-6Reference
Rear tire20x8.00-8Reference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear20x8.00-8Reference
Length170 cmReference
Width88 cmReference
Height (steering wheel)101 cmReference
AGCO 1615H attachments
38" mid-mount mower deckReference
44" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
44" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
