Lawn Tractor · 2007Unverified
AGCO 1825H
AGCO 1825H — Garden tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
302 kg
Hover a source tag to verify
Overview
DistributorAGCOReference
ManufacturerSimplicityReference
Garden tractorReference
Built in McDonough, Georgia, USAReference
Two-wheel driveReference
Differential lockmechanical rearReference
SteeringmanualReference
Steeringpower optionalReference
Disc brakesReference
Open operator station.Reference
Variants
Prestige 25similar Simplicity modelReference
2825Hsimilar Massey Ferguson modelReference
GT500similar Snapper modelReference
Engine
25HP Kohler 724cc 2-cyl gasolineReference
Fuel tank15.1 LReference
Kohler CV730SReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement44.2 ciReference
Bore/Stroke83 x 66 mmReference
Power (gross)18.6 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionTuff Torq K71Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Typesleeve hitchReference
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Weight302 kgReference
Front tire16x6.5-8Reference
Rear tire24x12-12Reference
Lawn/turf front16x6.5-8Reference
Lawn/turf rear24x12-12Reference
Length190 cmReference
Width104 cmReference
Height127 cmReference
Shipping weight302 kgReference
Front axleCast-ironReference
AGCO 1825H attachments
44" mid-mount mower deckReference
50" mid-mount mower deckReference
54" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps15Reference
Battery volts12Reference
Attachment overview
44" mid-mount mower deckReference
50" mid-mount mower deckReference
54" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
