Tractor · 1994Unverified
AGCO Allis 5650
AGCO Allis 5650 — SAME built · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Max power
32.7 kW
Weight
2041 kg
Hover a source tag to verify
Overview
DistributorAGCO AllisReference
ManufacturerSAMEReference
Built in ItalyReference
Original price was $22,000 in 1999Reference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS.Reference
Variants
Argon 50similar SAME modelReference
Engine
SLH 3.0L 3-cyl dieselReference
Fuel tank56.8 LReference
Drawbar (claimed)32.7 kWReference
Drawbar (tested)32.7 kWReference
SLH 1000.3Reference
dieselReference
3-cylinderReference
air-cooled inlineReference
Displacement3.0 LReference
Bore/Stroke105 x 116 mmReference
Pre-heatingthermostartReference
Compression17:1Reference
Rated RPM2350Reference
Starter volts12Reference
Power at rated engine speed35.0 kWReference
Max power32.7 kWReference
Transmission
12-speed sync shuttleReference
16-speedReference
Typesync shuttleReference
Gears12 forward and reverseReference
Four gears (1-4) in three ranges (low, medium, high) with synchronized shuttle. Gear shifts are synchronized.Reference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)35.6 kWReference
PTO (tested)35.0 kWReference
Typeopen centerReference
Valves2Reference
Pump flow45.0 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1888 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2079Reference
Power at rated PTO speed34.8 kWReference
Dimensions
2WD Wheelbase197 cmReference
4WD Wheelbase192 cmReference
Weight2041 kgReference
Front tire6.50-16Reference
Rear tire13.6R28Reference
Ag front6.50-16Reference
Ag rear13.6R28Reference
Length337 cmReference
Width169 cmReference
Height223 cmReference
2WD Front tread122 to 152 cmReference
4WD Front tread133 to 173 cmReference
Rear tread130 to 169 cmReference
5650 Serial Numbers
Location:Console, right sideReference
19941000Reference
19951001Reference
19961111Reference
19971255Reference
19981434Reference
19991516Reference
20001524Reference
20011551Reference
20021574Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Test results
Diesel 12-speed 4WDJuly 1993 - September 1993, Link: OCED Tractor Test 1497 fileReference
PTO performanceReference
Fuel use10.6 l/hourReference
Fuel use10.2 l/hourReference
Drawbar performanceReference
Fuel use13.2 l/hourReference
Gear 4N used for power test.Reference
Max pull1989 kgReference
Gear 3N used for pull test.Reference
Speeds
With 13.6R28 rear tires. Reverse speeds are 8% slower than forward speeds.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
