Tractor · 1991Unverified
AGCO Allis 7600
AGCO Allis 7600 — Row-Crop tractor · 89 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
89 hp
Weight
8179 to 9788 pounds
Hover a source tag to verify
Overview
DistributorAGCO Allis (a part of AGCO)Reference
ManufacturerSLHReference
Row-Crop tractorReference
Built in ItalyReference
Original price was $36,000 in 1996Reference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockmechanicalReference
Power steeringReference
Hydraulic wet disc brakesReference
Four-post ROPS. Cab optional with air-conditioning.Reference
Engine
SLH 5.2L 5-cyl dieselReference
Engine71.0 kWReference
SLH 1055-PReference
dieselReference
5-cylinderReference
air-cooled inlineReference
Displacement5.2 LReference
Bore/Stroke105 x 120 mmReference
Power71.0 kWReference
Fuel systemdirect injectionReference
Air cleanerdual dry elementReference
Compression17:1Reference
Rated RPM2180Reference
Idle RPM650-2374Reference
StarterelectricReference
Starter volts12Reference
Starter power3.5 kWReference
Oil capacity13.5 LReference
Transmission
24-speed synchromeshReference
TypesynchromeshReference
Gears24 forward and 12 reverseReference
Clutchhydraulic dry 350mm discReference
Oil capacity87.6 LReference
Four gears (1-4) in three ranges (L/M/H) with additional two-speed high-low shift.Reference
PTO & Hydraulics
PTO (claimed)66.6 kWReference
Hydraulic system87.4 LReference
Typeopen centerReference
Capacity87.4 LReference
Pressure180.0 barReference
Valves2Reference
Pump flow64.0 lpmReference
Rear TypeII/IReference
Controllower link draft controlReference
Rear lift (at ends)4599 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1957Reference
Engine RPM1000@2125Reference
Capacities
Fuel120.0 LReference
2WD Max capacity5200 kgReference
4WD Max capacity6799 kgReference
Dimensions
2WD Wheelbase265 cmReference
4WD Wheelbase264 cmReference
Weight8179 to 9788 poundsReference
Front tire10.00-16Reference
2WD Rear tire16.9R34Reference
2WD Standard tires (ag)Front: 10.00-16. Rear: 16.9R34Reference
4WD Standard tires (ag)Front: 14.9R24. Rear: 16.9R34Reference
2WD Length427 cmReference
4WD Length434 cmReference
Width213 cmReference
Height (exhaust)279 cmReference
2WD Ground clearance44 cmReference
4WD Ground clearance46 cmReference
Flange rear axleReference
2WD Front tread152 to 203 cmReference
4WD Front tread162 to 193 cmReference
Rear tread154 to 216 cmReference
2WD ROPS Shipping3709 kgReference
4WD ROPS Shipping4240 kgReference
2WD Cab Shipping3900 kgReference
4WD Cab Shipping4439 kgReference
7600 Serial Numbers
Location:Serial number plate on the right side of the 7600 console.Reference
19911001Reference
19921178Reference
19931193Reference
19941255Reference
19951359Reference
19961417Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
ROPS Charging amps55Reference
Cab Charging amps65Reference
Battery volts12Reference
Battery AH120Reference
Speeds
With 16.9R34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
