Tractor · 1991Unverified
AGCO Allis 7650
AGCO Allis 7650 — Row-Crop tractor · 128 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
128 hp
Weight
5699 kg
Hover a source tag to verify
Overview
DistributorAGCO Allis (a part of AGCO)Reference
ManufacturerSLHReference
Row-Crop tractorReference
Built in ItalyReference
Original price was $65,000 in 1994Reference
Four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockmechanical front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
SLH 6.2L 6-cyl dieselReference
Engine109.4 kWReference
SLH 1056-PSReference
turbocharged dieselReference
6-cylinderReference
air-cooledReference
Displacement6.2 LReference
Bore/Stroke105 x 120 mmReference
Power109.4 kWReference
Air cleanerdual dry elementReference
Compression16:1Reference
Rated RPM2180Reference
Idle RPM600-2354Reference
StarterelectricReference
Starter volts12Reference
Starter power3.5 kWReference
Oil capacity16.2 LReference
Transmission
24-speed synchromeshReference
TypesynchromeshReference
Gears24 forward and 12 reverseReference
Clutchhydraulic cerametallic 350mm discReference
Oil capacity97.4 LReference
Four gears (1-4) in three ranges (L/M/H) with additional two-speed high-low shift.Reference
PTO & Hydraulics
PTO (claimed)95.7 kWReference
Hydraulic system87.4 LReference
Typeopen centerReference
Capacity87.4 LReference
Pressure180.0 barReference
Valves2Reference
Pump flow64.0 lpmReference
Rear TypeIII/IIReference
Controllower link draft controlReference
Rear lift (at ends)5400 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2083Reference
Engine RPM1000@2136Reference
Capacities
Fuel210.1 LReference
Dimensions
Wheelbase290 cmReference
Weight5699 kgReference
Front tire16.9R30Reference
Rear tire20.8R38Reference
Standard tires (ag)Front: 16.9R30. Rear: 20.8R38Reference
Optional tires (ag)Front: 14.9R30. Rear: 18.4R38Reference
Length470 cmReference
Width218 cmReference
Height (exhaust)296 cmReference
Shipping weight5699 kgReference
Max weight8500 kgReference
Ground clearance51 cmReference
Flange rear axleReference
Front tread182 to 203 cmReference
Rear tread165 to 223 cmReference
7650 Serial Numbers
Location:Serial number plate on the right side of the 7650 console.Reference
19911001Reference
19921012Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps65Reference
Battery volts12Reference
Battery AH176Reference
Speeds
With 18.4R38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
