Tractor · 1991Unverified
AGCO Allis 9170
AGCO Allis 9170 — Row-Crop tractor · 173 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
173 hp
Max power
116.2 kW
Weight
7257 kg
Hover a source tag to verify
Overview
DistributorAGCO AllisReference
ManufacturerWhiteReference
Row-Crop tractorReference
Built in Coldwater, Ohio, USAReference
Original price was $68,000 in 1992Reference
Two- or four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockelectro-hydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Deutz 9.6L 6-cyl dieselReference
Fuel tank340.7 LReference
Drawbar (claimed)114.8 kWReference
Drawbar (tested)116.2 kWReference
Deutz BF6L513RReference
turbocharged dieselReference
6-cylinderReference
air-cooledReference
Displacement9.6 LReference
Bore/Stroke125 x 130 mmReference
Compression15.8:1Reference
Rated RPM2300Reference
Starter volts12Reference
Oil capacity22.2 LReference
Power at rated engine speed129.3 kWReference
Max power116.2 kWReference
Transmission
18-speed three-speed power shiftReference
Typethree-speed power shiftReference
Gears18 forward and 6 reverseReference
Clutch330mm dry discReference
Six forward gears, each with a three-speed power shift.Reference
PTO & Hydraulics
PTO (claimed)129.0 kWReference
PTO (tested)129.3 kWReference
Typeclosed centerReference
Pressure172.4 barReference
Valves2 or 3Reference
Pump flow90.8 lpmReference
Rear TypeIII/IIReference
Controlposition and draft controlReference
Rear lift (at ends)3460 kgReference
Rear lift (at ends)40255 kgReference
Rear PTOindependentReference
Rear PTO Type1000 (1.75)Reference
Engine RPM1000@2168Reference
Power at rated PTO speed133.3 kWReference
Dimensions
2WD Wheelbase302 cmReference
4WD Wheelbase292 cmReference
Weight7257 kgReference
Front tire11.00-16Reference
2WD Rear tire18.4R38Reference
2WD Standard tires (ag)Front: 11.00-16. Rear: 18.4R38Reference
4WD Standard tires (ag)Front: 14.9R28. Rear: 18.4R38Reference
Length508 cmReference
Width243 cmReference
Height (cab)307 cmReference
Height (exhaust)304 cmReference
Bar rear axle98 by 2438 mmReference
Bar rear axle98 by 2921 mmReference
2WD Front tread152 to 203 cmReference
4WD Front tread154 to 220 cmReference
Rear tread157 to 259 cmReference
9170 Serial Numbers
19891001Reference
19901163Reference
19912001Reference
199222500Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps105Reference
Batteries2Reference
Battery volts12Reference
Test results
Diesel 18-speed 2WDOctober 31 - November 15, 1989Link: Nebraska Tractor Test 1634 fileReference
PTO performanceReference
Fuel use41.6 l/hourReference
Fuel use40.5 l/hourReference
Drawbar performanceReference
Fuel use42.0 l/hourReference
Gear 3D used for power test.Reference
Max pull8630 kgReference
Gear 2D used for pull test.Reference
Speeds
With 18.4R38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
