Tractor · 2005Unverified

AGCO DT220A

Name: AGCO DT220A
Brand: AGCO

AGCO DT220A — DT-A Series · 229 hp. Reference specifications; pending source verification.

The AGCO DT220A tractor model is rated at approximately 229 hp, positioning it at the higher end of its class. It was produced between 2005 and 2008. The tractor features a 6-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with four-wheel drive and a continuously variable transmission. Its listed operating weight is 9049 kg, suitable for operations spanning 600-1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

229 hp

Max power

185.9 kW

Weight

9049 kg

Catalogue coverage

Variants represented

Richest spec table

64 rows

Recorded power

229 hp

Recorded weight

9049 kg

Transmissions

PowerMaxx CVT

Production years

2005-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAGCOReference

Row-Crop tractorReference

Built in Beauvais, FranceReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Hydraulic wet disc brakesReference

Cab standard with optional pneumatic suspension. Datatronics 3, Fieldstar, and Auto-Guide compatible.Reference

Variants

8470similar Massey Ferguson modelReference

Engine

Sisu Diesel 8.4L 6-cyl dieselReference

Fuel tank599.9 LReference

Engine193.9 kWReference

Drawbar (tested)149.5 kWReference

Sisu DieselReference

turbocharged intercooled dieselReference

6-cylinderReference

liquid-cooledReference

Displacement8.4 LReference

Bore/Stroke111 x 145 mmReference

EmissionsTier IIReference

Power193.9 kWReference

Air cleanertwo paper elementsReference

Pre-heatingthermostartReference

Rated RPM2200Reference

Starter volts12Reference

Max power185.9 kWReference

Power at rated engine speed170.4 kWReference

Max power149.5 kWReference

Transmission

continuously variable transmissionReference

TransmissionPowerMaxx CVTReference

Typecontinuously variable transmissionReference

Gearsinfinite forward and reverse (two-range)Reference

PTO & Hydraulics

PTO (claimed)164.1 kWReference

PTO (tested)185.9 kWReference

Typeclosed center pressure flow compensated (PFC)Reference

Pressure200.0 barReference

Valves4 or 5Reference

Total flow147.6 lpmReference

Rear Type3Reference

Rear lift (at 24"/610mm)6531 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Power at rated PTO speed184.9 kWReference

Dimensions

Wheelbase307 cmReference

Weight9049 kgReference

Length523 cmReference

Height309 cmReference

Shipping weight9049 kgReference

Front axleHydraMaxx optionalReference

DT220A Serial Numbers

Location:Rear of tractorReference

2005P001001Reference

2006R001001Reference

2007S001001Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Test results

Diesel CVT 4WDMay 2005 - July 2005, Link: OCED Tractor Test 2323 fileReference

PTO performanceReference

Fuel use53.7 l/hourReference

Fuel use53.4 l/hourReference

Drawbar performanceReference

Fuel use54.9 l/hourReference

Pull at 10.3 KPHReference

Max pull12333 kgReference

Pull at 4.1 KPHReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
