Tractor · 2009Unverified
AGCO DT275B
AGCO DT275B — DT-B Series · 281 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
281 hp
Max power
236.1 kW
Weight
10999 kg
Hover a source tag to verify
Overview
ManufacturerAGCOReference
Row-Crop tractorReference
Built in Beauvais, FranceReference
Original price was $231,833 in 2009Reference
The AGCO DT275B is the same as a Massey Ferguson 8680.Reference
Four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockfull locking electro-hydraulic front and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with heat and air-conditioning. Optional heated seat, power adjustable mirrors, and automatic temperature control. ISOBUS 11783 compatible. Auto-Guide optonal.Reference
Engine
AGCO SISU POWER 8.4L 6-cyl dieselReference
Fuel tank590.1 LReference
Fuel tank690.0 LReference
Exhaust fluid (DEF)29.9 LReference
Engine238.6 kWReference
Drawbar (tested)179.5 kWReference
AGCO SISU POWER 84CTAReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
The engine uses AGCO's e3 selective catalytic reduction (SCR) system to reduce nitrogen oxides (NOx). The system uses a diesel exhaust fluid that is injected into the exhaust gas. The engine could optionally be equipped with an exhaust gas recirculation (EGR) system in place of SCR.Reference
Displacement8.4 LReference
Bore/Stroke111 x 145 mmReference
EmissionsTier IIIReference
Emission controlselective catalytic reduction (SCR)Reference
Emission controlexhaust gas recirculation optional (EGR)Reference
Power238.6 kWReference
Maximum Power261.0 kWReference
Fuel systemhigh-pressure common railReference
Pre-heatingthermostartReference
Compression16.7:1Reference
Rated RPM2200Reference
Torque1491.6 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Max power236.1 kWReference
Power at rated engine speed209.7 kWReference
Max power179.5 kWReference
Max power240.6 kWReference
Power at rated engine speed210.8 kWReference
Max power176.2 kWReference
Transmission
continuously variable transmissionReference
TransmissionPowerMaxx CVTReference
Typecontinuously variable transmissionReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)205.1 kWReference
PTO (tested)240.6 kWReference
Typeclosed center load sensingReference
Pressure200.0 barReference
Valves4 to 6Reference
SCV flow99.9 lpmReference
Total flow174.9 lpmReference
Rear Type3Reference
Rear Type4 (optional)Reference
Rear lift (at ends)12002 kgReference
Rear lift (at 24"/610mm)9678 kgReference
Front Hitch3Reference
Front lift (at ends)4998 kgReference
DrawbarCategory 3Reference
DrawbarCategory 3 Heavy DutyReference
DrawbarCategory 4Reference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type1000E/1000 (1.75)Reference
Engine RPM1000@1970Reference
Engine RPM1000E@1605Reference
Front PTOoptionalReference
Front PTO Type1000Reference
Power at rated PTO speed228.9 kWReference
Power at rated PTO speed227.9 kWReference
Dimensions
Wheelbase310 cmReference
Weight10999 kgReference
Front tire420/85R34Reference
Rear tire480/80R50Reference
Standard tires (ag)Front: 420/85R34. Rear: 480/80R50Reference
Optional tires (ag)Front: 420/85R30. Rear: 520/85R42Reference
Optional tires (ag)Front: 420/90R30. Rear: 520/85R42Reference
Optional tires (ag)Front: 420/90R30. Rear: 480/80R46Reference
Optional tires (ag)Front: 420/85R34. Rear: 520/85R46Reference
Optional tires (ag)Front: 480/70R34. Rear: 520/85R46Reference
Optional tires (ag)Front: 480/70R34. Rear: 480/80R50Reference
Length547 cmReference
Height (cab)358 cmReference
Shipping weight10999 kgReference
Max weight17640 kgReference
Front axleSuspension optionalReference
Bar rear axle109 by 2997 mmReference
Bar rear axle109 by 2667 mmReference
Rear tread148 to 303 cmReference
AGCO DT275B attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps240Reference
Battery volts12Reference
Test results
OECD 2499: SCR diesel CVT 4WDReference
OECD 2559: EGR diesel CVT 4WDReference
SCR diesel CVT 4WDOctober 2008 - March 2009, Link: OCED Tractor Test 2499 fileReference
PTO performanceReference
Fuel use59.0 l/hourReference
Fuel use70.8 l/hourReference
Fuel use59.4 l/hourReference
Drawbar performanceReference
Fuel use56.8 l/hourReference
Pull at 8.4 KPHReference
Max pull16474 kgReference
Pull at 3.7 KPHReference
EGR diesel CVT 4WDOctober 2009 - March 2010, Link: OCED Tractor Test 2559 fileReference
Fuel use68.1 l/hourReference
Fuel use65.1 l/hourReference
Fuel use65.5 l/hourReference
Pull at 9.0 KPHReference
Max pull15279 kgReference
Pull at 4.1 KPHReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
