Tractor · 2002Unverified
AGCO LT70
AGCO LT70 — LT Series · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Max power
56.1 kW
Weight
7245 to 8650 pounds
Hover a source tag to verify
Overview
ManufacturerAGCOReference
Utility tractorReference
Built in Beauvais, FranceReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Engine
Cummins 3.9L 4-cyl dieselReference
Fuel tank128.7 LReference
Fuel tank189.2 LReference
Cummins 4BT3.9TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke102 x 120 mmReference
Air cleanerdual dry elementReference
Compression17.0:1Reference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Max power56.1 kWReference
Transmission
24-speed two-speed power shiftReference
12-speed mechanical shuttleReference
12-speedReference
Typetwo-speed power shiftReference
Gears24 forward and reverseReference
Clutchwet discReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)52.2 kWReference
PTO (tested)56.1 kWReference
Typeopen centerReference
Pressure210.0 barReference
SCV flow68.1 lpmReference
Total flow97.3 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)1859 kgReference
Rear lift (at 24"/610mm)2812 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Power at rated PTO speed55.8 kWReference
Dimensions
Wheelbase246 cmReference
Weight7245 to 8650 poundsReference
Length419 cmReference
Width210 cmReference
Height (cab)261 cmReference
2WD ROPS Shipping3286 kgReference
2WD Cab Shipping3696 kgReference
4WD Cab Shipping3923 kgReference
AGCO LT70 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
AGCO FL300 loaderReference
AGCO FL400 loaderReference
Test results
Diesel 12-speed 2WDMarch 16 - 17, 2000Link: Nebraska Tractor Test 1769 fileReference
PTO performanceReference
Fuel use17.4 l/hourReference
Fuel use18.2 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
