Tractor · 2002Unverified
AGCO LT85
AGCO LT85 — LT Series · 85 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
85 hp
Max power
65.6 kW
Hover a source tag to verify
Overview
ManufacturerAGCOReference
Utility tractorReference
Built in Beauvais, FranceReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post ROPS. Cab optional with air-conditioning.Reference
Engine
Cummins 3.9L 4-cyl dieselReference
Cummins 4BT3.9TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke102 x 120 mmReference
Air cleanerdual dry elementReference
Compression17.4:1Reference
Rated RPM2200Reference
Torque372.9 NmReference
Torque RPM1499Reference
Starter volts12Reference
Max power65.6 kWReference
Power at rated engine speed63.7 kWReference
Transmission
24-speed two-speed power shiftReference
12-speed mechanical shuttleReference
12-speedReference
Typetwo-speed power shiftReference
Gears24 forward and reverseReference
Clutchwet discReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)63.4 kWReference
PTO (tested)65.6 kWReference
Typeopen centerReference
Pump flow39.7 lpmReference
Pump flow70.0 lpmReference
Rear TypeIIReference
Rear lift1518 kgReference
Rear lift2600 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed65.5 kWReference
Dimensions
Wheelbase243 cmReference
AGCO LT85 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
AGCO FL300 loaderReference
AGCO FL400 loaderReference
Test results
Diesel 12-speed 2WDSeptember 14 - 23, 1999Link: Nebraska Tractor Test 1762 fileReference
PTO performanceReference
Fuel use19.7 l/hourReference
Fuel use21.2 l/hourReference
Fuel use20.4 l/hourReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
