Tractor · 2004Unverified
AGCO RT100
AGCO RT100 — RT Series · 102 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
102 hp
Max power
77.8 kW
Weight
11545 to 15055 pounds
Hover a source tag to verify
Overview
ManufacturerAGCOReference
Row-Crop tractorReference
Built in Beauvais, FranceReference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic front and rearReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Cab standard with optional automatic climate control.Reference
Engine
Cummins 6.7L 6-cyl dieselReference
Fuel tank264.9 LReference
Engine95.4 kWReference
Drawbar (tested)66.8 kWReference
CumminsReference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.7 LReference
Bore/Stroke104 x 132 mmReference
EmissionsTier IIReference
Power95.4 kWReference
Air cleanerdual paper elementsReference
Pre-heatinggrid heaterReference
Compression17.5:1Reference
Rated RPM2200Reference
Starter volts12Reference
Max power77.8 kWReference
Power at rated engine speed76.2 kWReference
Max power66.8 kWReference
Transmission
continuously variable transmissionReference
32-speed partial power shiftReference
TransmissionPowerMaxx CVTReference
Typecontinuously variable transmissionReference
Gearsinfinite forward and reverse (2-range)Reference
TransmissionQuadraShiftReference
Typepartial power shiftReference
Gears32 forward and reverseReference
Four power shift gears in four ranges.Reference
PTO & Hydraulics
PTO (claimed)74.6 kWReference
PTO (tested)77.8 kWReference
Typeclosed center pressure flow compensating (PFC)Reference
Pressure200.0 barReference
Valves3 or 4Reference
SCV flow109.8 lpmReference
Rear TypeII/IIINReference
Controlelectronic lower-linkReference
Rear lift (at 24"/610mm)4082 kgReference
Rear lift (at 24"/610mm)4762 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Front PTOoptionalReference
Power at rated PTO speed77.8 kWReference
Dimensions
Wheelbase278 cmReference
Weight11545 to 15055 poundsReference
Clearance (drawbar)35 cmReference
Front tread161 to 184 cmReference
Rear tread176 to 302 cmReference
Shipping5236 kgReference
Shipping5814 kgReference
Operating6828 kgReference
AGCO RT100 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Batteries2Reference
Battery volts12Reference
Test results
Diesel CVT 4WDJuly 2004 - October 2004, Link: OCED Tractor Test 2234 fileReference
PTO performanceReference
Fuel use24.6 l/hourReference
Fuel use26.1 l/hourReference
Drawbar performanceReference
Fuel use26.5 l/hourReference
Pull at 7.76 KPHReference
Max pull6774 kgReference
Pull at 2.60 KPHReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
