Tractor · 2006Unverified
AGCO RT120A
AGCO RT120A — RT-A Series · 123 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
123 hp
Max power
97.1 kW
Weight
13300 to 15100 pounds
Hover a source tag to verify
Overview
ManufacturerAGCOReference
Row-Crop tractorReference
Built in Beauvais, FranceReference
Original price$81,782 (2009 Auto-6 2WD )Reference
Original price$91,009 (2009 Auto-6 4WD )Reference
Original price$98,005 (2009 CVT 4WD )Reference
Two- or four-wheel driveReference
Differential lockfront and rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard. Optional Airmaxx pneumatic cab suspension and automatic climate control.Reference
Engine
SisuDiesel 6.6L 6-cyl dieselReference
Fuel tank378.5 LReference
Engine108.1 kWReference
Drawbar (tested)75.5 kWReference
SisuDiesel 66CTAReference
turbocharged intercooled dieselReference
6-cylinder 24-valveReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke108 x 120 mmReference
EmissionsTier IIIReference
Power108.1 kWReference
Maximum Power126.8 kWReference
Fuel systemelectronic common rail fuel injectionReference
Air cleanerdry cartridgeReference
Pre-heatinggrid heaterReference
Compression18.5:1Reference
Rated RPM2200Reference
Starter volts12Reference
Max power97.1 kWReference
Power at rated engine speed91.5 kWReference
Max power75.5 kWReference
Max power109.8 kWReference
Power at rated engine speed95.3 kWReference
Max power72.4 kWReference
Transmission
24-speed partial power shiftReference
continuously variable transmissionReference
TransmissionAuto-6Reference
Typepartial power shiftReference
Gears24 forward and reverseReference
Clutchwet discReference
Six power shift gears in four synchromesh ranges. Autodrive provides automatic shifting to match load.Reference
TransmissionPowerMaxx CVTReference
Typecontinuously variable transmissionReference
Gearsinfinite forward and reverse (two-range)Reference
Combination hydrostatic-mechanical CVT transmission. With the suspended front axle a transport speed of 50 KPH is available. Creeper speed available down to 0.03 KPH.Reference
PTO & Hydraulics
PTO (claimed)89.5 kWReference
PTO (tested)109.8 kWReference
Typeclosed center pressure flow compensated (PFC)Reference
Pressure200.0 barReference
Valves2 to 4Reference
Total flow109.8 lpmReference
Rear Type2Reference
Controlelectronic position and draft controlReference
Rear lift (at 24"/610mm)4259 kgReference
CVT Rear lift (at 24"/610mm)4762 kgReference
Front HitchoptionalReference
Front lift3991 kgReference
Rear PTOindependentReference
Rear PTO Type540/540E/1000/1000EReference
Front PTOoptionalReference
Front PTO Type1000Reference
Power at rated PTO speed95.2 kWReference
Power at rated PTO speed107.3 kWReference
Dimensions
2WD Wheelbase292 cmReference
4WD Wheelbase288 cmReference
Weight13300 to 15100 poundsReference
Front tire10.00x16Reference
Rear tire18.4R42 (2WD)Reference
Standard tires (ag)Front: 10.00x16. Rear: 18.4R42 (2WD)Reference
Standard tires (ag)Front: 14.9R30. Rear: 18.4R42 (4WD)Reference
2WD Length464 cmReference
4WD Length434 cmReference
2WD Width154 cmReference
4WD Width199 cmReference
2WD Height (cab)361 cmReference
4WD Height (cab)290 cmReference
Bar rear axle82 by 2227 mmReference
Bar rear axle82 by 2870 mmReference
CVT95 by 2468 mm Bar rear axle3.75 by 97.2 inchesReference
CVT95 by 2999 mm Rear axle3.75 by 118.1 inchesReference
2WD Front tread162 to 202 cmReference
4WD Front tread162 to 202 cmReference
Rear tread169 to 292 cmReference
4WD Shipping6032 kgReference
CVT Shipping6849 kgReference
4WD Operating6679 kgReference
CVT Operating6849 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps120Reference
Charging amps150Reference
Batteries2Reference
Battery CCA550Reference
Battery volts12Reference
Test results
OECD 1904: diesel CVT 4WDReference
OECD 2412: diesel 24-speed 4WDReference
Diesel CVT 4WDMay 23 - 29, 2007Link: OCED Tractor Test 1904 fileReference
PTO performanceReference
Fuel use27.3 l/hourReference
Fuel use29.9 l/hourReference
Fuel use28.4 l/hourReference
Drawbar performanceReference
Fuel use29.5 l/hourReference
Pull at 7.75 KPHReference
Max pull6826 kgReference
Pull at 3.65 KPHReference
Diesel 24-speed 4WDNovember 2007 - January 2008, Link: OCED Tractor Test 2412 fileReference
Fuel use30.7 l/hourReference
Fuel use31.0 l/hourReference
Fuel use25.7 l/hourReference
Gear 3A used for power test.Reference
Max pull6017 kgReference
Gear 1D used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
