Tractor · 2003Unverified
AGCO ST22A
AGCO ST22A — ST-A Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
620 kg
Hover a source tag to verify
Overview
DistributorAGCOReference
ManufacturerIsekiReference
Sub-Compact Utility tractorReference
Built in Matsuyama, JapanReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post fixed ROPS.Reference
Variants
GC2300similar Massey Ferguson modelReference
Engine
Iseki 1.1L 3-cyl dieselReference
Fuel tank20.8 LReference
Engine (gross)16.8 kWReference
IsekiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power (gross)16.8 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Hydro PTO (claimed)13.8 kWReference
Gear PTO (claimed)14.2 kWReference
Typeopen centerReference
Pump flow15.5 lpmReference
Rear TypeIReference
Rear lift (at ends)539 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase145 cmReference
Weight620 kgReference
Length247 cmReference
Width116 cmReference
Height183 cmReference
Shipping weight620 kgReference
AGCO ST22A attachments
54" mid-mount mower deckReference
60" mid-mount mower deckReference
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
54" mid-mount mower deckReference
60" mid-mount mower deckReference
Front-end loaderReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
