Tractor · 2005Unverified
AGCO ST24A
AGCO ST24A — ST-A Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
709 kg
Hover a source tag to verify
Overview
DistributorAGCOReference
ManufacturerIsekiReference
Compact Utility tractorReference
Built in Matsuyama, JapanReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post fixed ROPS.Reference
Engine
Iseki 1.1L 3-cyl dieselReference
Engine (gross)16.8 kWReference
IsekiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power (gross)16.8 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
6-speed gearReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)14.2 kWReference
Typeopen centerReference
Pump flow20.1 lpmReference
Rear TypeIReference
Rear lift (at ends)550 kgReference
Rear lift (at 24"/610mm)400 kgReference
Rear PTOtransmission (gear)Reference
Rear PTOindependent (hydrostatic)Reference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase152 cmReference
Weight709 kgReference
Length267 cmReference
Width100 cmReference
Height196 cmReference
Shipping weight709 kgReference
AGCO ST24A attachments
60" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount AGCO SM60AReference
Type3-bladeReference
Cutting width152 cmReference
AGCO SH15A Backhoe
Backhoe typeAGCO SH15A BackhoeReference
Digging depth198 cmReference
Reach from pivot259 cmReference
Swing Arc140°Reference
Bucket force884 kgReference
Dipperstick force535 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
