Tractor · 2005Unverified

AGCO ST28A

Name: AGCO ST28A
Brand: AGCO

AGCO ST28A — ST-A Series · 28 hp. Reference specifications; pending source verification.

The AGCO ST28A is a tractor rated at approximately 28 hp, positioning it at the lower end of its class. It was produced from 2005 to 2008. The ST28A features a 3-cylinder diesel liquid-cooled engine paired with four-wheel drive and a hydrostatic transmission. Its listed operating weight is 1000 kg, making it suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Weight

1000 kg

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

28 hp

Recorded weight

1000 kg

Transmissions

hydrostatic

Production years

2005-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorAGCOReference

ManufacturerIsekiReference

Compact Utility tractorReference

Built in Matsuyama, JapanReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Iseki 1.5L 3-cyl dieselReference

Engine (gross)21.2 kWReference

IsekiReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke86 x 84 mmReference

Power (gross)21.2 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

9-speedReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

TransmissiongearReference

Gears9 forward and 3 reverseReference

PTO & Hydraulics

Hydro PTO (claimed)16.6 kWReference

Gear PTO (claimed)18.3 kWReference

Typeopen centerReference

Pump flow28.0 lpmReference

Rear TypeIReference

Rear lift (at ends)1099 kgReference

Rear lift (at 24"/610mm)730 kgReference

Rear PTOtransmission (gear)Reference

Rear PTOindependent (hydrostatic)Reference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2000Reference

Dimensions

Wheelbase166 cmReference

Weight1000 kgReference

Length291 cmReference

Width125 cmReference

Height200 cmReference

Shipping weight1000 kgReference

AGCO ST28A attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

AGCO SH15A Backhoe

Backhoe typeAGCO SH15A BackhoeReference

Digging depth198 cmReference

Reach from pivot259 cmReference

Swing Arc180°Reference

Bucket force1088 kgReference

Dipperstick force657 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
