Tractor · 2001Unverified
AGCO ST30
AGCO ST30 — ST Series · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
1176 kg
Hover a source tag to verify
Overview
DistributorAGCOReference
ManufacturerIsekiReference
Compact Utility tractorReference
Built in Matsuyama, JapanReference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
1235similar Massey Ferguson modelReference
Engine
Iseki 1.5L 3-cyl dieselReference
Engine (gross)22.6 kWReference
Engine (net)21.7 kWReference
Iseki E3CDReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power (net)21.7 kWReference
Power (gross)22.6 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Pre-heatingglow plugsReference
Compression21.8Reference
Rated RPM2500Reference
Idle RPM950-2750Reference
Torque97.1 NmReference
Torque RPM1800Reference
StarterelectricReference
Starter volts12Reference
Oil capacity4.7 LReference
Coolant capacity7.1 LReference
Transmission
9-speed gearReference
hydrostaticReference
TypegearReference
Gears9 forward and 3 reverseReference
Clutch225mm mechanical dry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)18.3 kWReference
Hydro PTO (claimed)16.6 kWReference
Hydraulic system12.1 LReference
Typeopen centerReference
Capacity12.1 LReference
Pressure146.9 barReference
Pump flow22.7 lpmReference
Total flow32.2 lpmReference
Steering flow9.5 lpmReference
Steering press.117.7 barReference
Rear TypeIReference
Controlposition controlReference
Controldraft controlReference
Rear lift (at ends)899 kgReference
Rear lift (at 24"/610mm)544 kgReference
Rear Armsfixed link ends with turn-buckle stabilizersReference
Rear PTOlive (gear)Reference
Rear PTOindependent (hydro)Reference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2327Reference
Mid PTOliveReference
Clutchdry discReference
Mid PTO TypeSAE 15 1.0Reference
Engine RPM2000@2482Reference
Capacities
Fuel23.1 LReference
Dimensions
Wheelbase166 cmReference
Weight1176 kgReference
Front tire6.00-14Reference
Rear tire12.4-16Reference
Weight341 kgReference
Standard tires (ag)Front: 6.00-14. Rear: 12.4-16Reference
Lawn/turf front24x8.50-12Reference
Lawn/turf rear315/80D-16Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear13.6-16Reference
Industrial front25x8.50-14Reference
Industrial rear12.5/80-18Reference
Length295 cmReference
Width140 cmReference
Height (ROPS)201 cmReference
Shipping weight1176 kgReference
Max weight1898 kgReference
Flange rear axleReference
Front tread96 cmReference
Rear tread109 cmReference
AGCO ST30 attachments
60" mid-mount mower deckReference
72" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA582Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
72" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
AGCO SH16 Backhoe
Backhoe typeAGCO SH16 BackhoeReference
Transport height162 cmReference
Bucket width25 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
2-Foot flat digging depth200 cmReference
Reach from pivot254 cmReference
Bucket Rotation165°Reference
Swing Arc180°Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
