The AGCO ST33A is a compact tractor with a rated output of 33 hp, characterised by its compact design. It was manufactured between 2005 and 2008. The 3-cylinder diesel liquid-cooled engine drives the four-wheel drive system, which is equipped with a hydrostatic transmission. The tractor weighs 1000 kg and is suited to tasks covering areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
1000 kg
Catalogue coverage
Variants represented
2
Richest spec table
57 rows
Recorded power
33 hp
Recorded weight
1000 kg
Transmissions
hydrostatic
Production years
2005-2008
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorAGCOReference
ManufacturerIsekiReference
Compact Utility tractorReference
Built in Matsuyama, JapanReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Engine (gross)24.6 kWReference
Iseki E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power (gross)24.6 kWReference
Fuel systemindirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)19.3 kWReference
Typeopen centerReference
Pump flow29.1 lpmReference
Rear TypeIReference
Rear lift (at ends)1099 kgReference
Rear lift (at 24"/610mm)730 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase166 cmReference
Weight1000 kgReference
Length291 cmReference
Width125 cmReference
Height200 cmReference
Shipping weight1000 kgReference
AGCO ST33A attachments
60" mid-mount mower deckReference
72" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
72" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
AGCO SH16A Backhoe
Backhoe typeAGCO SH16A BackhoeReference
Digging depth198 cmReference
Reach from pivot259 cmReference
Swing Arc180°Reference
Bucket force1088 kgReference
Dipperstick force657 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
