Tractor · 2005Unverified

AGCO ST34A

Name: AGCO ST34A
Brand: AGCO

AGCO ST34A — ST-A Series · 33 hp. Reference specifications; pending source verification.

The AGCO ST34A is a tractor model with a rated power output of 33 hp, positioning it at the lower end of its class. Production of the ST34A took place from 2005 to 2008. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine and four-wheel drive, paired with a hydrostatic transmission. Its operating weight is listed at 1290 kg, suitable for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

33 hp

Weight

1290 kg

Catalogue coverage

Variants represented

Richest spec table

72 rows

Recorded power

33 hp

Recorded weight

1290 kg

Transmissions

8-speed synchro shuttle

Production years

2005-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorAGCOReference

ManufacturerIsekiReference

Compact Utility tractorReference

Built in Matsuyama, JapanReference

Four-wheel driveReference

Final drivesspur gearReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Iseki 1.5L 3-cyl dieselReference

Engine (gross)24.6 kWReference

Iseki E3CDReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke87 x 84 mmReference

Power (gross)24.6 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

8-speed synchro shuttleReference

12-speed power shuttleReference

hydrostaticReference

Typesynchro shuttleReference

Gears8 forward and reverseReference

Typepower shuttleReference

Gears12 forward and reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

Hydro PTO (claimed)18.3 kWReference

Gear PTO (claimed)19.4 kWReference

Typeopen centerReference

Pump flow34.4 lpmReference

Rear TypeIReference

Controlposition control with optional draft controlReference

Rear lift (at ends)1270 kgReference

Rear lift (at 24"/610mm)1149 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2000Reference

Dimensions

Wheelbase177 cmReference

Weight1290 kgReference

Length307 cmReference

Width157 cmReference

Height (ROPS)205 cmReference

Shipping weight1290 kgReference

Ground clearance35 cmReference

AGCO ST34A attachments

60" mid-mount mower deckReference

72" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

72" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

AGCO SH17A Backhoe

Backhoe typeAGCO SH17A BackhoeReference

Digging depth228 cmReference

Reach from pivot284 cmReference

Swing Arc180°Reference

Bucket force1474 kgReference

Dipperstick force861 kgReference

AGCO SH19A Backhoe

Backhoe typeAGCO SH19A BackhoeReference

Digging depth254 cmReference

Reach from pivot322 cmReference

Swing Arc180°Reference

Bucket force1886 kgReference

Dipperstick force1179 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
