Tractor · 2005Unverified
AGCO ST41A
AGCO ST41A — ST-A Series · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
1309 kg
Hover a source tag to verify
Overview
DistributorAGCOReference
ManufacturerIsekiReference
Compact Utility tractorReference
Built in Matsuyama, JapanReference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Engine (gross)29.9 kWReference
Iseki E3CD-TReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power (gross)29.9 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchro shuttleReference
12-speed power shuttleReference
hydrostaticReference
Typesynchro shuttleReference
Gears8 forward and reverseReference
Typepower shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Hydro PTO (claimed)22.0 kWReference
Gear PTO (claimed)23.1 kWReference
Typeopen centerReference
Pump flow34.4 lpmReference
Rear TypeIReference
Controlposition control with optional draft controlReference
Rear lift (at ends)1270 kgReference
Rear lift (at 24"/610mm)1149 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase177 cmReference
Weight1309 kgReference
Length307 cmReference
Width157 cmReference
Height (ROPS)205 cmReference
Shipping weight1309 kgReference
Ground clearance35 cmReference
AGCO ST41A attachments
60" mid-mount mower deckReference
72" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
72" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
AGCO SH17A Backhoe
Backhoe typeAGCO SH17A BackhoeReference
Digging depth228 cmReference
Reach from pivot284 cmReference
Swing Arc180°Reference
Bucket force1474 kgReference
Dipperstick force861 kgReference
AGCO SH19A Backhoe
Backhoe typeAGCO SH19A BackhoeReference
Digging depth254 cmReference
Reach from pivot322 cmReference
Swing Arc180°Reference
Bucket force1886 kgReference
Dipperstick force1179 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
