Tractor · 2003Unverified
AGCO ST55
AGCO ST55 — ST Series · 56 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
56 hp
Weight
2003 kg
Hover a source tag to verify
Overview
DistributorAGCOReference
ManufacturerIsekiReference
Compact Utility tractorReference
Built in Matsuyama, JapanReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Iseki 2.8L 4-cyl dieselReference
Fuel tank48.1 LReference
Engine (gross)41.5 kWReference
IsekiReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
Power (gross)41.5 kWReference
Fuel systemindirect injectionReference
Rated RPM2500Reference
Starter volts12Reference
Transmission
12-speed synchro shuttleReference
Typesynchro shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)34.0 kWReference
Typeopen centerReference
Pressure156.9 barReference
Pump flow43.1 lpmReference
Total flow65.5 lpmReference
Steering flow22.3 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1399 kgReference
Rear Armstelescopic link endsReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase200 cmReference
Weight2003 kgReference
Front tire7.5-16Reference
Rear tire13.6-28Reference
Ag front7.5-16Reference
Ag rear13.6-28Reference
Ag front35x12.00-16.5Reference
Ag rear14.9-28Reference
Lawn/turf front29x12.00-15Reference
Lawn/turf rear475/65D-20Reference
Industrial front10x16.5Reference
Industrial rear17.5Lx24Reference
Length347 cmReference
Width184 cmReference
Height (ROPS)250 cmReference
Height (Folded ROPS)191 cmReference
Shipping weight2003 kgReference
Ground clearance32 cmReference
Front tread138 cmReference
Rear tread144 to 157 cmReference
AGCO ST55 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
