Tractor · Unverified
AgraCat 2940
AgraCat 2940 — Jinma built · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1242 kg
Hover a source tag to verify
Overview
DistributorAgraCatReference
ManufacturerJinmaReference
Built in ChinaReference
Four-wheel driveReference
Engine
3-cyl dieselReference
Engine18.6 kWReference
XN2100/385Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Power18.6 kWReference
Rated RPM2350Reference
Starter typeelectricReference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)17.7 kWReference
Pressure220.6 barReference
Total flow36.6 lpmReference
Rear TypeIReference
Rear lift397 kgReference
Rear PTOlive (two-stage clutch)Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase164 cmReference
Weight1242 kgReference
Front tire6.00-16Reference
Rear tire9.5-24Reference
Ag front6.00-16Reference
Ag rear9.5-24Reference
Length299 cmReference
Width129 cmReference
Height (steering wheel)144 cmReference
Shipping weight1242 kgReference
Ground clearance29 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
