Tractor · 2007Unverified
AgTrac AT2514
AgTrac AT2514 — Compact Utility tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1412 kg
Hover a source tag to verify
Overview
DistributorAgTracReference
ManufacturerDongfengReference
Compact Utility tractorReference
Built in Changzhou, Jiangsu, ChinaReference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Disc brakesReference
Two-post folding ROPS. Canopy optional.Reference
Engine
Changchai 1.8L 3-cyl dieselReference
Engine18.6 kWReference
Changchai ZN390TReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.8 LReference
Bore/Stroke90 x 95 mmReference
Power18.6 kWReference
Fuel systemdirect injectionReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Four-speed with high and low ranges.Reference
PTO & Hydraulics
Rear TypeIReference
Rear lift (at 24"/610mm)423 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase170 cmReference
Weight1412 kgReference
Length330 cmReference
Width157 cmReference
Height (steering wheel)149 cmReference
Ground clearance28 cmReference
Front tread114 cmReference
Rear tread115 to 135 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
