Tractor · 2007Unverified
AgTrac AT3024
AgTrac AT3024 — Compact Utility tractor · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
1559 kg
Hover a source tag to verify
Overview
DistributorAgTracReference
ManufacturerDongfengReference
Compact Utility tractorReference
Built in Changzhou, Jiangsu, ChinaReference
The AgTrac 3024 is simlar to the DongFeng 304G2.Reference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Two-post folding ROPS. Canopy optional.Reference
Engine
Changchai 1.8L 3-cyl dieselReference
Engine22.4 kWReference
Changchai ZN390TIReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.8 LReference
Bore/Stroke90 x 95 mmReference
Power22.4 kWReference
Fuel systemdirect injectionReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Four-speed shuttle with high and low ranges.Reference
PTO & Hydraulics
Rear TypeIReference
Rear lift (at 24"/610mm)474 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase170 cmReference
Weight1559 kgReference
Length320 cmReference
Width157 cmReference
Height (steering wheel)157 cmReference
Ground clearance29 cmReference
Front tread109 cmReference
Rear tread112 cmReference
AgTrac AT3024 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
