Tractor · 2007Unverified
AgTrac AT3814
AgTrac AT3814 — Compact Utility tractor · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1656 kg
Hover a source tag to verify
Overview
DistributorAgTracReference
ManufacturerDongfengReference
Compact Utility tractorReference
Built in Changzhou, Jiangsu, ChinaReference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Power steeringReference
Two-post folding ROPS. Canopy optional.Reference
Engine
Changchai 2.5L 3-cyl dieselReference
Engine26.1 kWReference
Changchai ZN490TIReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement2.5 LReference
Bore/Stroke90 x 100 mmReference
Power26.1 kWReference
Fuel systemdirect injectionReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Four-speed shuttle with high and low ranges.Reference
PTO & Hydraulics
Rear TypeIReference
Rear lift (at 24"/610mm)661 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase183 cmReference
Weight1656 kgReference
Length340 cmReference
Width152 cmReference
Height (steering wheel)157 cmReference
Ground clearance40 cmReference
Front tread124 cmReference
Rear tread109 to 139 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
