Lawn Tractor · 1982Unverified
Allis Chalmers 1036 Sprint
Allis Chalmers 1036 Sprint — Sprint Series · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
162 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Riding lawn mowerReference
Original price was $1,799 in 1984Reference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
10HP Briggs & Stratton 361cc 1-cyl gasolineReference
Fuel tank2.8 LReference
Briggs & Stratton 220707Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement22.04 ciReference
Bore/Stroke87 x 60 mmReference
Power7.5 kWReference
Air cleaneroiled foamReference
StarterelectricReference
Starter volts12Reference
Transmission
5-speed gearReference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
Clutchidler pulleyReference
Dimensions
Wheelbase111 cmReference
Weight162 kgReference
Front tire4.10/3.50-4Reference
Rear tire16x6.50-8Reference
Lawn/turf front4.10/3.50-4Reference
Lawn/turf rear16x6.50-8Reference
Length154 cmReference
Width78 cmReference
Height (steering wheel)96 cmReference
Allis Chalmers 1036 attachments
36" mid-mount mower deckReference
1036 Serial Number Location
Serial number decal near the foot pan, below the seat.Reference
Electrical
GroundnegativeReference
Charging amps3Reference
Battery volts12Reference
36" Mower deck
Typemid-mount Allis ChalmersReference
Type2-blade with manual liftReference
Cutting width91 cmReference
Overall width116 cmReference
Cut height3 to 8 cmReference
Cut positions6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
