Tractor · 1967Unverified
Allis Chalmers 170
Allis Chalmers 170 — Row-Crop tractor · 54 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Max power
35.3 kW
Weight
5720 to 5950 pounds
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Row-Crop tractorReference
Total built9,303Reference
Original price$6,887 (1973)Reference
Two-wheel driveReference
Steeringhydraulic power assistReference
Differential mechanical contracting band and disc brakesReference
Open operator station.Reference
Engine
Perkins 3.9L 4-cyl dieselReference
Allis Chalmers 3.7L 4-cylReference
Drawbar (tested)35.3 kWReference
Perkins 4.236Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Compression16:1Reference
Rated RPM1800Reference
Firing order1-3-4-2Reference
Coolant capacity14.2 LReference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.254 mmReference
Oil capacity6.6 LReference
Allis Chalmers G-226Reference
Displacement3.7 LReference
Bore/Stroke102 x 114 mmReference
Compression8:1Reference
Firing order1-2-4-3Reference
Sparkplug gap0.635 mmReference
Point gap0.559 mmReference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.356 mmReference
Oil capacity5.7 LReference
Power at rated engine speed40.3 kWReference
Max power35.3 kWReference
Power at rated engine speed40.4 kWReference
Max power35.0 kWReference
Transmission
8-speed two-speed power shiftReference
TransmissionPower DirectorReference
Typetwo-speed power shiftReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
Oil capacity22.7 LReference
The transmission is controlled by means of the gear shift lever and the Power Director lever. The tractor must be stopped, and clutch used, to select one of four forward gears, or reverse. The Power Director lever has high, low, and neutral positions. The Power Director can be shifted on the move without clutching. Placing the Power Director into neutral causes the tractor to stop while keeping the PTO engaged.Reference
PTO & Hydraulics
PTO (tested)40.4 kWReference
Hydraulic system24.6 LReference
TypeopenReference
Capacity24.6 LReference
Pressure137.9 barReference
Valves1Reference
Pump flow69.3 lpmReference
Steering flow22.7 lpmReference
Rear TypeIIReference
Rear PTOliveReference
Rear PTO Type540Reference
Power at rated PTO speed37.7 kWReference
Power at rated PTO speed38.4 kWReference
Capacities
Fuel70.0 LReference
Dimensions
Wheelbase242 cmReference
Weight5720 to 5950 poundsReference
Front tire6.00x16Reference
Rear tire16.9-28Reference
Ag front6.00x16Reference
Ag front6.50x16Reference
Ag front7.50x16Reference
Ag front7.50x20 (cane)Reference
Ag front9.00x10Reference
Ag rear16.9-28Reference
Length381 cmReference
Width198 cmReference
Ground clearance52 cmReference
Ground clearance79 cmReference
Operating2594 kgReference
Operating2698 kgReference
Ballasted4154 kgReference
Allis Chalmers 170 attachments
front-end loaderReference
170 Serial Numbers
Location:Front of torque housing flangeReference
19671005Reference
19682721Reference
19695374Reference
19706369Reference
19716988Reference
19727797Reference
19738821Reference
Final10300Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH60 (gas)Reference
Battery AH95 (diesel)Reference
Allis Chalmers 170 Height
149 cmReference
171 cmReference
227 cmReference
Test results
NTTL 965: diesel 8-speed 2WDReference
NTTL 966: gasoline 8-speed 2WDReference
Diesel 8-speed 2WDOctober 13 - 27, 1967Link: Nebraska Tractor Test 965 fileReference
PTO performanceReference
Fuel use12.5 l/hourReference
Fuel use11.7 l/hourReference
Drawbar performanceReference
Fuel use12.9 l/hourReference
Gear 5 used for power test.Reference
Max pull3121 kgReference
Gear 1 used for pull test.Reference
Gasoline 8-speed 2WDOctober 16 - 27, 1967Link: Nebraska Tractor Test 966 fileReference
Fuel use16.3 l/hourReference
Fuel use15.1 l/hourReference
Fuel use16.7 l/hourReference
Max pull3107 kgReference
Speeds
With 16.9x28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
