Tractor · 1967Unverified
Allis Chalmers 180
Allis Chalmers 180 — Row-Crop tractor · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Max power
41.2 kW
Weight
6420 to 6510 pounds
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Row-Crop tractorReference
Built in West Allis, Wisconsin, USAReference
Total built11,750 (total)Reference
Total built10,163 (diesel)Reference
Total built1,587 (gas)Reference
Original price$7,474Reference
Two-wheel driveReference
Steeringhydraulic powerReference
Differential disc brake band acutated brakesReference
Open operator station.Reference
Engine
Allis Chalmers 4.9L 6-cyl dieselReference
Allis-Chalmers 4.3L 6-cyl gasolineReference
Drawbar (claimed)41.2 kWReference
Drawbar (tested)41.8 kWReference
Allis Chalmers 2800Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement4.9 LReference
Bore/Stroke98 x 108 mmReference
Compression16.25:1Reference
Rated RPM2000Reference
Firing order1-5-3-6-2-4Reference
Starter volts12Reference
Coolant capacity16.1 LReference
Intake valve clearance0.381 mmReference
Exhaust valve clearance0.381 mmReference
Oil capacity9.5 LReference
Allis-ChalmersReference
gasolineReference
Displacement4.3 LReference
Bore/Stroke95 x 102 mmReference
Compression8.15:1Reference
Oil capacity11.4 LReference
Power at rated engine speed47.7 kWReference
Max power41.2 kWReference
Power at rated engine speed48.6 kWReference
Max power41.8 kWReference
Transmission
8-speed partial powershiftReference
TransmissionPower DirectorReference
Typepartial powershiftReference
Gears8 forward and 2 reverseReference
Oil capacity22.7 LReference
The transmission is controlled by means of the gear shift lever and the Power Director lever. The tractor must be stopped, and clutch used, to select one of four forward gears, or reverse. The Power Director lever has high, low, and neutral positions. The Power Director can be shifted on the move without clutching. Placing the Power Director into neutral causes the tractor to stop while keeping the PTO engaged.Reference
PTO & Hydraulics
PTO (claimed)47.7 kWReference
PTO (tested)48.6 kWReference
Hydraulic system34.1 LReference
Typeopen centerReference
Capacity34.1 LReference
Valves2Reference
Pump flow37.9 lpmReference
Steering flow22.0 lpmReference
Steering press.137.9 barReference
Rear TypeIIReference
Rear PTOtransmissionReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000Reference
Engine RPM540@1964Reference
Power at rated PTO speed47.7 kWReference
Power at rated PTO speed48.2 kWReference
Capacities
Fuel93.1 LReference
Diameter22 cmReference
Width16 cmReference
RPM1677Reference
Speed1203.96 meters/minReference
Dimensions
Wheelbase251 cmReference
Weight6420 to 6510 poundsReference
Front tire6.50-16Reference
Rear tire14.9/13-28Reference
Ag front6.50-16Reference
Ag front7.50-16Reference
Ag front9.00-10Reference
Ag rear14.9/13-28Reference
Ag rear16.9/14-28Reference
Ag rear18.4/15-28Reference
Ag rear23.1/18-26Reference
Ag rear15.5-3818.4-28Reference
Length401 cmReference
Width194 cmReference
Clearance (front axle)52 cmReference
Clearance (rear axle)80 cmReference
Gas Operating2912 kgReference
Diesel Operating2952 kgReference
Ballasted4658 kgReference
Steering wheel211 cmReference
Allis Chalmers 180 attachments
front-end loaderReference
180 Serial Numbers
Location:Front of torque housingReference
19671007Reference
19682682Reference
19696094Reference
19709235Reference
197110561Reference
197211729Reference
197312447Reference
Final12985Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemDelco-Remy alternatorReference
Charging amps32Reference
Batteries1Reference
Batteries2Reference
Battery volts12Reference
Battery AH95Reference
Allis Chalmers 180 Height
89 cmReference
Hood163 cmReference
Exhaust229 cmReference
Test results
NTTL 964: diesel 8-speed 2WDReference
NTTL 1005: gasoline 8-speed 2WDReference
Diesel 8-speed 2WD10/13/1967Link: Nebraska Tractor Test 964 fileReference
PTO performanceReference
Fuel use15.9 l/hourReference
Drawbar performanceReference
Gear 4 used for power test.Reference
Gasoline 8-speed 2WDApril 8 - 14, 1969Link: Nebraska Tractor Test 1005 fileReference
Fuel use22.3 l/hourReference
Fuel use22.0 l/hourReference
Speeds
With 16.9-28 rear tires.Reference
