Tractor · 1982Unverified
Allis Chalmers 5015
Allis Chalmers 5015 — Sub-Compact Utility tractor · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
1278 to 1448 pounds
Hover a source tag to verify
Overview
DistributorAllis ChalmersReference
ManufacturerHinomotoReference
Sub-Compact Utility tractorReference
Built in Osaka, JapanReference
Original price was $6,549 in 1985Reference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Two post ROPS. Optional ROPS canopy.Reference
Variants
9518similar Simplicity modelReference
Engine
Toyosha 1.0L 3-cyl dieselReference
Engine13.4 kWReference
Toyosha CS-100Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke73 x 80 mmReference
Power13.4 kWReference
Air cleanerdryReference
Compression22.5:1Reference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity2.2 LReference
Coolant capacity3.0 LReference
Transmission
9-speed gearReference
TypegearReference
Gears9 forward and 3 reverseReference
Oil capacity17.0 LReference
PTO & Hydraulics
PTO (claimed)11.2 kWReference
Hydraulic system17.0 LReference
Typeopen centerReference
Capacity17.0 LReference
Valves0 or 1Reference
Rear TypeIReference
Controlposition controlReference
Rear PTOcontinuousReference
Rear PTO Type540 (1.375)Reference
Capacities
Fuel14.0 LReference
Dimensions
Wheelbase129 cmReference
Weight1278 to 1448 poundsReference
Front tire4-12Reference
2WD Rear tire8-18Reference
2WD Standard tires (ag)Front: 4-12. Rear: 8-18Reference
4WD Standard tires (ag)Front: 5-14. Rear: 8-18Reference
Lawn/turf front20.5x8-10Reference
Lawn/turf rear29x12-15Reference
Length210 cmReference
Width103 cmReference
Height (steering wheel)119 cmReference
Height (hood)103 cmReference
Clearance (front axle)34 cmReference
Clearance (rear axle)36 cmReference
629 kgReference
2WD Shipping579 kgReference
4WD Shipping656 kgReference
Allis Chalmers 5015 attachments
48" mid-mount mower deckReference
54" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
5015 Serial Numbers
Location:Serial number plate under steering wheel, ahead of the gear shift lever.Reference
19821001Reference
19831727Reference
19843277Reference
19854232Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
48" mid-mount mower deckReference
54" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
Speeds
With 8-18 R1 rear tires.Reference
