Lawn Tractor · 1982Unverified
Allis Chalmers 526 Sprint
Allis Chalmers 526 Sprint — Sprint Series · 5 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
5 hp
Weight
124 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Riding lawn mowerReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
5HP Briggs & Stratton 206cc 1-cyl gasolineReference
Fuel tank1.9 LReference
Briggs & Stratton 130902Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement12.57 ciReference
Bore/Stroke65 x 62 mmReference
Power3.7 kWReference
Air cleaneroiled foamReference
Starter typemanual recoilReference
Oil capacity0.8 LReference
Transmission
5-speed gearReference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
Clutchidler pulleyReference
Dimensions
Wheelbase111 cmReference
Weight124 kgReference
Front tire10.50x3.50Reference
Rear tire15x6.00-6Reference
Lawn/turf front10.50x3.50Reference
Lawn/turf rear15x6.00-6Reference
Length154 cmReference
Width76 cmReference
Height (steering wheel)96 cmReference
Allis Chalmers 526 attachments
26" mid-mount mower deckReference
26" Mower deck
Typemid-mount Allis ChalmersReference
Type1-blade with manual liftReference
Cutting width66 cmReference
Overall width88 cmReference
Cut height3 to 8 cmReference
Cut positions6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
