Lawn Tractor · 1980Unverified
Allis Chalmers 608 LTD
Allis Chalmers 608 LTD — 600 Lawn Series · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
227 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Lawn tractorReference
Built in Port Washington, Wisconsin, USAReference
Original price was $1,929 in 1984Reference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
8HP Briggs & Stratton 318cc 1-cyl gasolineReference
Fuel tank8.3 LReference
Briggs & Stratton 191707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement19.44 ciReference
Bore/Stroke76 x 70 mmReference
Power6.0 kWReference
Air cleanerfoamReference
Rated RPM3600Reference
Idle RPM1800-3400Reference
Starter volts12Reference
Oil capacity1.1 LReference
Transmission
5-speed gearReference
ManufacturerPeerlessReference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
1ThrottleReference
2Clutch/brakeReference
3Gear shiftReference
Dimensions
Wheelbase115 cmReference
Weight227 kgReference
Front tire13-5.00x6Reference
Rear tire18-8.50x8Reference
Weight36 kgReference
Lawn/turf front13-5.00x6Reference
Lawn/turf rear18-8.50x8Reference
Length159 cmReference
Width87 cmReference
Height99 cmReference
Ground clearance13 cmReference
Allis Chalmers 608 LTD attachments
36" mid-mount mower deckReference
snowblowerReference
bladeReference
608 LTD Serial Number Location
Serial number plate on the left side of Allis 608 LTD, above the foot rest.Reference
Links
SimpleTractors.com: information, photos and old advertising literature at SimpleTractors.comReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
36" mid-mount mower deckReference
SnowblowerReference
BladeReference
36" Mower deck
Typemid-mount Allis-ChalmersReference
Type2-blade with manual liftReference
Cutting width91 cmReference
Overall width116 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
