Tractor · 1980Unverified
Allis Chalmers 6080
Allis Chalmers 6080 — Row-Crop tractor · 84 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
84 hp
Max power
52.6 kW
Weight
2948 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Row-Crop tractorReference
Built in West Allis, Wisconsin, USAReference
Total built6,698Reference
Original price was $30,000 in 1985Reference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Differential hydraulic wet disc brakesReference
Four-post ROPS canopy. Optional cab and air-conditoning.Reference
Engine
Allis Chalmers 3.3L 4-cyl dieselReference
Drawbar (tested)52.6 kWReference
Allis Chalmers 433TIReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke98 x 108 mmReference
Air cleanerpaper element with precleanerReference
Compression14.1:1 (early)Reference
Compression15.5:1 (late)Reference
Rated RPM2300Reference
Starter volts12Reference
Oil capacity9.5 LReference
Coolant capacity16.1 LReference
Power at rated engine speed62.4 kWReference
Max power52.6 kWReference
Transmission
12-speed synchronizedReference
TypesynchronizedReference
Gears12 forward and 3 reverseReference
Oil capacity11.4 LReference
Four gears in three ranges. Synchronized shifting using the clutch.Reference
PTO & Hydraulics
PTO (tested)62.4 kWReference
Typeopen centerReference
Valves2Reference
Pump flow43.1 lpmReference
Total flow71.9 lpmReference
Rear TypeIIReference
Rear lift (at 24"/610mm)2041 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Power at rated PTO speed55.5 kWReference
Capacities
Fuel121.1 LReference
Rear diff.35.0 LReference
Dimensions
Wheelbase243 cmReference
Wheelbase242 cmReference
Weight2948 kgReference
Front tire7.50-16Reference
Rear tire18.4-34Reference
Ag front7.50-16 (2WD)Reference
Ag front11.2-28 (4WD)Reference
Ag rear18.4-34 (2WD)Reference
Ag rear16.9-34 (4WD)Reference
Length379 cmReference
Width185 cmReference
Operating weight2948 kgReference
Ballasted weight5347 kgReference
Ground clearance44 cmReference
Ground clearance53 cmReference
Ground clearance67 cmReference
Allis Chalmers 6080 attachments
front-end loaderReference
6080 Serial Number Location
Serial number on the engine adapter housing, right sideReference
6080 Serial Numbers
19801001Reference
19811152Reference
19823002Reference
19834567Reference
19845780Reference
19856853Reference
Final7698Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemalternatorReference
Charging amps72Reference
Batteries1Reference
Batteries2 (optional)Reference
Battery volts12Reference
Allis Chalmers 6080 Height
Hood176 cmReference
ROPS273 cmReference
Cab262 cmReference
Exhaust279 cmReference
Test results
Diesel 12-speed 2WDJune 8 - 20, 1981Link: Nebraska Tractor Test 1398 fileReference
PTO performanceReference
Fuel use18.9 l/hourReference
Fuel use17.8 l/hourReference
Drawbar performanceReference
Fuel use18.5 l/hourReference
Gear 4-I used for power test.Reference
Max pull4083 kgReference
Gear 1-I used for pull test.Reference
Speeds
With 18.4x34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
