Lawn Tractor · 1983Unverified
Allis Chalmers 611 Hydro
Allis Chalmers 611 Hydro — 600 Lawn Series · 11 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
11 hp
Weight
249 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Lawn tractorReference
Built in Port Washington, Wisconsin, USAReference
Original price was $2,499 in 1984Reference
Two-wheel driveReference
SteeringmanualReference
Disc brakesReference
Open operator station.Reference
Variants
4211Hsimilar Simplicity modelReference
Engine
11HP Briggs & Stratton 399cc 1-cyl gasolineReference
Fuel tank8.3 LReference
Briggs & Stratton 252707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement24.36 ciReference
Bore/Stroke87 x 67 mmReference
Power8.2 kWReference
Air cleanerfoamReference
Rated RPM3600Reference
Idle RPM1750-3400Reference
Starter volts12Reference
Oil capacity1.4 LReference
Transmission
hydrostaticReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity0.7 LReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Mid PTO TypepulleyReference
Dimensions
Wheelbase115 cmReference
Weight249 kgReference
Front tire13-6.00x6Reference
Rear tire18-8.50x8Reference
Weight36 kgReference
Lawn/turf front13-6.00x6Reference
Lawn/turf rear18-8.50x8Reference
Length165 cmReference
Width85 cmReference
Height (steering wheel)99 cmReference
Height (hood)85 cmReference
Ground clearance13 cmReference
Clearance (front axle)23 cmReference
Allis Chalmers 611 Hydro attachments
36" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging amps3Reference
Battery volts12Reference
Attachment overview
36" mid-mount mower deckReference
SnowblowerReference
BladeReference
36" Mower deck
Typemid-mount Allis-ChalmersReference
Type3-blade with manual liftReference
Cutting width91 cmReference
Overall width116 cmReference
Cut height3 to 8 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
