Industrial Tractor · 1970Unverified
Allis Chalmers 650
Allis Chalmers 650 — Industrial Crawler tractor · 59 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
59 hp
Weight
8900 to 14719 pounds
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Industrial Crawler tractorReference
DrivecrawlerReference
Open operator station.Reference
Variants
650crawlerReference
652dozerReference
653dozerReference
655crawler loaderReference
Engine
Allis Chalmers 3.3L 4-cyl dieselReference
Engine (gross)44.0 kWReference
Allis Chalmers 433Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke99 x 108 mmReference
Power (gross)44.0 kWReference
Air cleanerdryReference
Compression16.25:1Reference
Rated RPM2100Reference
Torque207.5 NmReference
Torque RPM1700Reference
StarterelectricReference
Starter volts12Reference
Oil capacity11.4 LReference
Coolant capacity15.1 LReference
Transmission
3-speed torque converterReference
Typetorque converterReference
Gears3 forward and reverseReference
Oil capacity11.6 LReference
Capacities
Fuel94.6 LReference
PTO & Hydraulics
Hydraulic system53.9 LReference
Typeopen centerReference
Capacity53.9 LReference
Pump flow56.8 lpmReference
Pump flow94.6 lpmReference
Dimensions
Weight8900 to 14719 poundsReference
12-inch tracksReference
Length276 cmReference
652 dozer length373 cmReference
653 dozer length365 cmReference
Width160 cmReference
Height (hood)186 cmReference
Height (exhaust)203 cmReference
Clearance (drawbar)25 cmReference
Gauge129 cmReference
6504037 kgReference
6525275 kgReference
6535103 kgReference
6556676 kgReference
Allis Chalmers 650 attachments
bladeReference
front-end loaderReference
Attachment overview
BladeReference
Front-end loaderReference
Allis Chalmers 650 Tracks
Width30 cmReference
Length on ground177 cmReference
Area on ground0.5 m²Reference
Ground pressure0.6 barReference
Width35 cmReference
Area on ground1.3 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
