Backhoe Loader · 1978Unverified

Allis Chalmers 714B

Name: Allis Chalmers 714B
Brand: Allis Chalmers

Allis Chalmers 714B — Backhoe loader tractor · 72 hp. Reference specifications; pending source verification.

The Allis Chalmers 714B is a backhoe loader rated at roughly 72 hp, a mid-range figure for its class. The 714B ran in production from 1978 to 1980. Power comes from a 4-cylinder diesel liquid-cooled engine, paired with two-wheel drive with a 4-speed gearbox. It has a listed operating weight of 5896 kg, and it suits operations of up to 200 ac. Full UK and US specifications are listed below, each with its source.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

72 hp

Weight

5896 kg

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

72 hp

Recorded weight

5896 kg

Transmissions

4-speed torque converter

Production years

1978-1980

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerAllis ChalmersReference

Backhoe loader tractorReference

Two-wheel driveReference

Power steeringReference

Wet disc brakesReference

Four-post ROPS.Reference

Variants

714B14-ft backhoeReference

715B15-ft backhoeReference

Engine

Perkins 3.9L 4-cyl dieselReference

Engine (gross)53.7 kWReference

Engine (net)48.5 kWReference

Perkins 4.236Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.9 LReference

Bore/Stroke98 x 127 mmReference

Power (net)48.5 kWReference

Power (gross)53.7 kWReference

Compression16:1Reference

Rated RPM2250Reference

Torque252.2 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity11.4 LReference

Coolant capacity18.9 LReference

Transmission

4-speed torque converterReference

TransmissionWarnerReference

Typetorque converterReference

Gears4 forward and reverseReference

Dimensions

Wheelbase213 cmReference

Weight5896 kgReference

Front tire11Lx16Reference

Rear tire16.9x24Reference

Industrial front11Lx16Reference

Industrial rear16.9x24Reference

Length716 cmReference

Width210 cmReference

Height (ROPS)251 cmReference

Front tread170 cmReference

Rear tread165 cmReference

Operating5896 kgReference

Max front axle5670 kgReference

Max rear axle5670 kgReference

Backhoe & Loader

Dig depth426 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Allis Chalmers Backhoe

Backhoe typeAllis Chalmers BackhoeReference

Digging depth426 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
