Lawn Tractor · 1982Unverified
Allis Chalmers 830 Sprint
Allis Chalmers 830 Sprint — Sprint Series · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
143 kg
Hover a source tag to verify
Overview
ManufacturerAllis ChalmersReference
Riding lawn mowerReference
Original price was $1,659 in 1984Reference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
8HP Briggs & Stratton 318cc 1-cyl gasolineReference
Fuel tank2.8 LReference
Briggs & Stratton 190707Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement19.44 ciReference
Bore/Stroke76 x 70 mmReference
Power6.0 kWReference
Air cleaneroiled foamReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.0 LReference
Transmission
5-speed gearReference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
Clutchidler pulleyReference
Dimensions
Wheelbase111 cmReference
Weight143 kgReference
Front tire4.10/3.50-4Reference
Rear tire16x6.50-8Reference
Lawn/turf front4.10/3.50-4Reference
Lawn/turf rear16x6.50-8Reference
Length154 cmReference
Width78 cmReference
Height (steering wheel)96 cmReference
Allis Chalmers 830 attachments
30" mid-mount mower deckReference
830 Serial Numbers
Location:Serial number decal near the foot pan, below the seat.Reference
Electrical
GroundnegativeReference
Charging amps3Reference
Battery volts12Reference
30" Mower deck
Typemid-mount Allis ChalmersReference
Type1-blade with manual liftReference
Cutting width76 cmReference
Overall width99 cmReference
Cut height3 to 8 cmReference
Cut positions6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
